What are our Products?

RFIC Solutions has a number of pre release products in mmWave MMICs. Released products will be available as chips or packaged part at a competitive price. These can be ordered based on the enquiry and MOQ of at least 5000 units from the customer. We have selected some products from our IP list that have wide applicability in various industries like 5G, SATCOM, Fixed Wireless Access, etc. We can further make more products from our available IP if there is more customer demand in the future.

  • ARNA Series
Sr.No. IP ID Type TX/RX Process Technology Freq (GHz) Gain (dB) (Tx/Rx) OP1dB(Tx Path)/IP1dB (Rx Path)(dBm) OIP3(Tx Path)/IIP3(Rx Path) (dBm) Psat NF in Rx path (dB) IRL (Tx/Rx) ORL (Tx/Rx) Isolation (Tx/Rx) VDD (V) (Tx/Rx) ID (mA) (Tx/Rx)ApplicationQuotePre-Release
15GICFE02FE Beamformer BA-PS-VVA-DA-PA/LNA-VVA-LNA-PS 0.1 um GaAs pHEMT 24-30 27/2420/-16 30/-11 2 6.9/13 12.4/10 4/8 960/2805G, Satcom, Wireless Application

DataSheet

Sr.No.IP ID Type Functional Blocks(TX/RX/LO) Process Technology RF Freq/LOx2 Freq/IF Freq (GHz) Conversion Gain (dB) (Tx/Rx) OP1dB(Tx Path)/IP1dB (Rx Path)(dBm) OIP3(Tx Path)/IIP3(Rx Path) (dBm) Image Rejection(dBc) NF in Rx path (dB) RF RL (Tx/Rx) LO RL (Tx/Rx) IF RL (Tx/Rx) VDD (V) (Tx/Rx) ID(mA) (Tx/Rx)ApplicationQuotePre-Release
15GICUD01 UP DOWN CONVERTER IF Amp-UPC-PA/IF Amp-DNC-LNA/BA-X2-1-DA-PD 0.1 um GaAs pHEMT 24-30/14-18/5-6 24/2620/-1330/0253.7-12/-15-12/-15-15/-14 4 1343/6255G.SATCOM.Backhaul

Datasheet

  • Mixer

Sr.No.IP ID Type Process Technology Freq (GHz) LO Freq (GHz)IF Freq (GHz) Conversion Loss (dB) IIP3 (dBm) Isolation (dB) Image Rejection (dB) ApplicationDatasheet/QuoteProduction Status
1RFICDC01 DNC Mixer 0.1 um GaAs pHEMT 24 to 30 26 to 36 2-6 9.5 2020155G,SATCOM,Backhaul

Pre-Release

  • Amplifiers

Sr.No.IP IDType Process Technology Freq (GHz) Gain (dB) OP1dB (dBm) OIP3 (dBm) PsatNF (dB) VDD (V) ID (mA) ApplicationDatasheet/QuoteProduction Status
1RFICDA03
Driver-Amp
0.1 um GaAs pHEMT
18-23
2716-202.731045G, Satcom, Backhaul

Pre-Release
2RFICLN05 Low Noise Amplifier 0.1 um GaAs pHEMT 12-15 20 20.7 28 22 1.1 4 62.7 5G, Satcom, Backhaul

Pre-Release
3RFICDA05 Driver-Amp 0.1 um GaAs pHEMT 12-18 15 17 - 21 5.4 4 86 5G, Satcom, Backhaul

Pre-Release
4RFICGB01 Gain-Block 0.1 um GaAs pHEMT 1.5-6 16 20 32.421 1.7 4 60 5G, Satcom, Backhaul

Pre-Release
5RFICLN06 Low Noise Amplifier0.1 um GaAs pHEMT12-2217 14 24 18 1.4 4 625G, Satcom, Backhaul

Pre-Release
6RFICLN09
Low Noise Amplifier 0.1 um GaAs pHEMT 50-66 20 11 20 -5.5 4 209.8 5G, Satcom, Backhaul

Pre-Release
7RFICLN10 Low Noise Amplifier 0.1 um GaAs pHEMT 50-70 18 10 18 18 5 4 209.8 5G, Satcom, Backhaul

Pre-Release

  • Switch

Sr.No. IP ID Type Process Technology
Freq (GHz) Insertion Loss (dB) OP1dB(dBm)OIP3 (dBm)Isolation (dB)ApplicationsDatasheetProduction Status
1RFICSW01TR-Switch 0.1 um GaAs pHEMT (EMR)22 to 281.2 333430 5G,Backhaul,SATCOM

Pre-Release

  • Frequency Multiplier

Sr.No.IP IDType Process Technology
Input Freq (GHz)Output Freq (GHz)Conversion Gain (dB)Output Power (dBm)Harmonic suppresion (dBc)VDDIDDVSSISSApplicationDatasheetProduction Status
1RFIPX201Doubler0.1 um GaAs pHEMT4.5 to 5.759 to 11.54425435-526Wireless Application

Pre-Release
2RFIPX202Doubler0.1 um GaAs pHEMT 9 to 11.518 to 23-8325437-526Wireless Application

Pre-Release
3 RFICX203 Doubler 0.1 um GaAs pHEMT 12-18 24-36 -8.81.320 4 43-426 5G,SATCOM,WiGig

Pre-Release
